Chilli Powder Packing Machine

Chilli powder packing machine can pack powdwr material, it is widely use in food, chemical, building, agriculture, Veterinary medicine and other industries.

Send Inquiry

Description

Chilli Powder Packing Machine

Introduction

Turmeric powder packing machine is a small-dose quantitative packaging machine, suitable for small quantitative packaging of powdery materials in the chemical, food, agricultural and sideline products industries. Particularly suitable for quantitative packaging machines for more expensive products.

Feature

1. Microcomputer control, parameters can be adjusted, and errors can be automatically corrected;

2. Easy to use, not restricted by the production site;

3. Good anti-corrosion performance, no pollutants;

4. The part in contact with the material is made of 304 stainless steel, which meets the food and medical packaging standards.

5. PLC control, low failure rate and higher reliability

6. Use digital AC servo motor to control the feeding, with high control precision

7. Working parameters can be stored for later use; avoiding re-calibration when changing materials in cycles.

Technical parameters

Brand:	KAIYU
Manufacturer:	Zhengzhou KaiYu packaging Equipment Co., Ltd.
Measurement Range:	10-5000g (Need different Augers and Auger Funnels)
Measurement Method:	Auger Filler
Filled Error:	≤ ±1%
Filling Speed:	0-50 fills/min
Contact Materials:	Food Grade SUS304 Stainless Steel
Entrance Height:	1600mm(Adjusted)
Entrance Diameter:	150mm
Control System:	PLC Touch Screen
Monitorable Hopper:	Yes
Easy Clean Hopper:	Optional
Fill Control:	Timer based / Sensor based
Dimensions:	800× 750×2000mm
Power:	AC Three-Phase 380V 50Hz 2.5Kw
Hopper Capacity:	50 L-70L(Customizable)
Optional	1. Screw elevator 2. Pulse dust collector 3. Bottle/Can sealing machine 4. Conveyor belt 5. Mixer 6. Labeling machine 7. Coding machine 8. Bottle unscrambler 9. Sealing machine
